FSR series of metal detectors are specifically designed for high demand of sensitivity, stability and intelligent detection. On bases of core invention patents and patented self-adaptable algorithm, plus with combination of the world’s famous component units, integrated circuits and ARM+FPGA structural frame, FSR series metal detectors contribute the leading detecting performance in the industry.
Feature
●Hard fill technology handpiece
●US Ferroelectric RAM
●German SEW motor
●SUS 304 roller bearing
●High Quality Food Grade PU conveyor belt
●Japanese SMC pneumatic components (optional)
●Denmark Danfoss frequency converter (optional)
●Full Stainless steel 304 Frame
●Detector is made by hard filling technology with first-class stability.
●Intelligent learning function, automatically parameter setting, easy operation
●X-R orthogonal decomposition and multiple filtering algorithm, better anti-interference
●Phase intelligent tracking technology and automatic balance adaptive technology
●Anti-interference photoelectric isolation drive, remote installation of the operation panel
●DDS all-digital and digital signal processing technology improves detection accuracy
●US ferroelectric RAM, lossless storage of 50 product parameters
●It can detect various metal materials such as iron, stainless steel, copper, aluminum and lead
Technical Data
Model-FSR | 4520 | 4525 | 6020 | 6030 | 7520 | 7530 | ||
Detecting Width (mm) | 450 | 450 | 600 | 600 | 750 | 750 | ||
Detecting Height (mm) | 200 | 250 | 200 | 300 | 200 | 250 | ||
Valid Detecting Size W*H (mm) | 400*170 | 400*220 | 550*170 | 550*270 | 700*170 | 700*220 | ||
Sensitivity ≥(Фmm)
| Fe | 1.0 | 1.2 | 1.0 | 1.5 | 1.0 | 1.5 | |
Non-Fe | 1.5 | 1.8 | 1.5 | 2.0 | 1.5 | 2.0 | ||
SUS304 | 2.0 | 2.3 | 2.0 | 2.5 | 2.0 | 2.5 | ||
Loading Capacity | 25kg | 25kg | 50kg | 50kg | 100kg | 100kg | ||
Belt Width (mm) | 370 | 370 | 520 | 520 | 670 | 670 | ||
Conveyor Length (mm) | 1800 | 2000 | 1800 | 2000 | 1800 | 2000 | ||
Belt Height (mm) | 700-820mm / 780-900mm or Customized | |||||||
Detecting Method | Belt stop and Auto Alarm | |||||||
Rejector Device | Pusher, Flipper, Flap Down, Down Belt (By Options) | |||||||
Voltage Power | AC110V-240V, 50/60Hz, 1ph | |||||||
Belt Speed | 28m/min |
