FSR series of metal detectors are specifically designed for high demand of sensitivity, stability and intelligent detection, and have core invention patents. Select imported famous brand components and integrated circuits, adopt ARM+FPGA architecture design, cooperate with advanced technologies such as patented adaptive algorithms, to achieve industry-leading detection performance
Feature
●Hard fill technology handpiece
●US Ferroelectric RAM
●Japanese Oriental motor
●SUS 304 roller bearing
●High Quality Food Grade PU conveyor belt
●Japanese SMC pneumatic components (optional)
●Denmark Danfoss frequency converter (optional)
●Full Stainless steel 304 Frame
●Detector is made by hard filling technology with first-class stability.
●Intelligent learning function, automatically parameter setting, easy operation
●X-R orthogonal decomposition and multiple filtering algorithm, better anti-interference
●Phase intelligent tracking technology and automatic balance adaptive technology
●Anti-interference photoelectric isolation drive, remote installation of the operation panel
●DDS all-digital and digital signal processing technology improves detection accuracy
●US ferroelectric RAM, lossless storage of 50 product parameters
●It can detect various metal materials such as iron, stainless steel, copper, aluminum and lead
Technical Data
Model-FSR | 2510 | 2512 | 3012 | 3015 | 3512 | 3515 |
Detecting Width (mm) | 250 | 250 | 300 | 300 | 350 | 350 |
Detecting Height (mm) | 100 | 120 | 120 | 150 | 120 | 150 |
Valid Detecting Size W*H (mm) | 200*70 | 200*90 | 250*90 | 250*120 | 300*90 | 300*120 |
Sensitivity ≥(Фmm) | Fe | 0.5 | 0.6 | 0.6 | 0.8 | 0.6 | 0.7 |
Non-Fe | 0.7 | 0.8 | 0.8 | 1.0 | 0.8 | 1.0 |
SUS304 | 1.0 | 1.2 | 1.2 | 1.5 | 1.2 | 1.5 |
Loading Capacity | 10kg | 10kg | 20kg | 20kg | 20kg | 20kg |
Belt Width (mm) | 180 | 180 | 230 | 230 | 280 | 280 |
Conveyor Length (mm) | 1200 | 1500 | 1200 | 1500 | 1500 | 1500 |
Belt Height (mm) | 700-820mm / 780-900mm or Customized |
Detecting Method | Belt stop and Auto Alarm |
Rejector Device | Air Jet, Pusher, Flipper, Flap Down, Down Belt (By Options) |
Voltage Power | AC110V-240V, 50/60Hz, 1ph |
Belt Speed | 28m/min |
