The FPS Series scale is a reliable and heavy duty scale system for weighing granulates products like seeds, plastic pellets, mineral ores etc., its weighing range cover from 1kg to 50kg (By different models). The pneumatically actuated buckets can be supplied in a variety of sizes to maximize product flow and weighing accuracy. It's for granule matter industries of food, feed and chemical, etc..



The complete packaging line is consisting of linear scale with pneumatic bag clamper, belt conveyor and sewing or sealing machine.



Samples



Feature

●Rugged and dependable design

●Convenient to be operated; Easy to be installed

●Stainless steel product contact surfaces

●Matching high precision sensor with high intelligent meter

●Software set-adopting, error automatically amended, more/less alarming trouble self-inspected functions etc.

●Number and quantity of package automatically counting printing and data communication functions

●Widely range of quantitative and high precision and matching with a bag-sewing machine which has multi-functions and high effective can be provided



Technical Data

Scale Heads Quantity	Single Head		Double Head
Model	FPS-1-10K	FPS-1-25K	FPS-2-10K	FPS-2-25K
Rated Packing Weight(KG)	1-10	10-25	1-10	10-25
Division Value(g)	2	10	2	10
Speed(bags/hour)	＞300	＞300	＞600	＞600
Accuracy	0.1-0.2%
Working Environment	Temperature 0-40℃;    Humidity≤90%
Power	220V or 380V, 0.6KW
Air Consumption	0.4-0.8MPa 1.2m³/h
