Standard Combination Scale







The standard multi-head combination scale, rapid and accurate, weighs granules in a combined way. It is suitable for various products, including granular particles, slice, roll or irregular shaped material, such as nuts, preserved fruit, cookies, candies, jelly, coffee beans, chocolate, potato chips, pet food, and small hardware or plastic components.




Feature

●Waterproof and dustproof design, convenient for cleaning and maintenance;

●7.0” LCD touch screen with 15 languages for selection, easy for operation;

●Standard design with exchangeable spare parts.

●Program can be recovered to the initial.

●HBM digital load cell of high precision ensures the accuracy.

●Independently adjustable linear amplitude improves the distribution.

●The best combination is selected automatically and instantly among possible combinations.

●The ready hoppers of combination can be preset to unload product alternately as to avoid blockage.

●Automatic stop for lack of product makes combination more stable.

●Speed-oriented weighing model or accuracy-oriented weighing model can be chosen to meet different requirements.



Technical Data

Model

FCS-10H

FCS-14H

Weighing   Range

10-1000g

10-1500g

Weighing   Accuracy

X(0.5)

Max.   Weighing Speed

65bpm

120bpm

Hopper   Volume

1.6L/ 2.5L

Driving   System

Step motor

Optional   Devices

Dimpled hopper/ timing hopper/ printer/ reject device

Control   Panel

7.0” touch screen

Power

220V/ 1000W/ 50/60HZ/ 10A

220V/ 1500W/ 50/60HZ/ 12A

Machine   Weight

380kg

490kg

Packing   Dimension (mm)

1620(L)x 1100(W)x 1110 (H)

1700(L)x 1110(W)x 1130 (H)
