● Easy integration of auger filling, linear scale, combination scale dosing systems.

● Continuous processing system with material feeding, bag shaping, filling, vacuuming, sealing and coding

● Packed bag keep high quality in sealing, long-life&nnbsp;in reserving, smart in looking

● Fault alarm shut down and message display

● Film auto tracking, Length registered by photoelectric-eye & Encoder



Technical Specifications

Bag style	Vacuum Brick Shape
Bag Height	Up to 340mm ( 13.4'')
Film width	≤540mm (21.2'')
Bagger Power Consumption	3KW
Vacuum Power Consumption	3.5KW
Vacuum Compressed Air Request	0.65Mpa, 0.65-1.2 M3/min
Vacuum pump flow	40 M3/Hr
